DIN 553 Slotted Set Screw with Cone Point China Origin Supplier with High Quality and Good Price

DIN 553 Slotted Set Screws with Cone Point

DIN 553 Slotted Set Screws with Cone Point are a type of fastener commonly used in industrial applications. These set screws have a slotted head and a cone-shaped point, allowing for easy installation and secure fastening.

Manufactured according to the DIN 553 standard, these set screws meet specific dimensions and tolerances, ensuring consistent quality and compatibility with other components.

They are made from high-quality materials such as stainless steel, carbon steel, or alloy steel, providing durability and corrosion resistance.

DIN 553 Slotted Set Screws with Cone Point Details

SIZE: M1 - M12

MATEAIL: Carbon Steel, Stainless Steel, Copper

STANDARD: DIN 553, ISO 7434, DIN EN 27434

SURFACE TREATMENT: ZP, HDG, BLACK, Dacromet

CUSTOMIZED SUPPORT: YES

DIN 553 Slotted Set Screws with Cone Point Specifications

    Screw Thread
d
    M1
    M1.2
    M1.4
    M1.6
    M2
    M2.5
    M3
    (M3.5)
    M4
    M5
    M6
    M8
    M10
    M12



    P
    Pitch
25
25
3
35
4
45
5
6
7
8
    1
25
5
75


    d1
    max
1
12
14
16
2
25
3
35
4
5
5
    2
5
    3


    n
    Nominal Size
2
2
2
25
25
4
4
5
6
8
    1
2
6
    2


    min
26
26
26
31
31
46
46
56
66
86
06
26
66
06


    max
4
4
4
45
45
6
6
7
8
    1
2
51
91
31


    t
    min=nominal size
4
4
48
56
64
72
8
96
12
28
6
    2
4
8


    max
52
52
63
74
84
95
05
21
42
63
    2
5
    3
6


Screw Thread d	M1	M1.2	M1.4	M1.6	M2	M2.5	M3	(M3.5)	M4	M5	M6	M8	M10	M12
P	Pitch	0.25	0.25	0.3	0.35	0.4	0.45	0.5	0.6	0.7	0.8	1	1.25	1.5	1.75
d1	max	0.1	0.12	0.14	0.16	0.2	0.25	0.3	0.35	0.4	0.5	1.5	2	2.5	3
n	Nominal Size	0.2	0.2	0.2	0.25	0.25	0.4	0.4	0.5	0.6	0.8	1	1.2	1.6	2
min	0.26	0.26	0.26	0.31	0.31	0.46	0.46	0.56	0.66	0.86	1.06	1.26	1.66	2.06
max	0.4	0.4	0.4	0.45	0.45	0.6	0.6	0.7	0.8	1	1.2	1.51	1.91	2.31
t	min=nominal size	0.4	0.4	0.48	0.56	0.64	0.72	0.8	0.96	1.12	1.28	1.6	2	2.4	2.8
max	0.52	0.52	0.63	0.74	0.84	0.95	1.05	1.21	1.42	1.63	2	2.5	3	3.6

Equivalent Standard for DIN 553 Slotted Set Screws with Cone Point - ISO 7434

DIN EN ISO 7434 Hexagon Socket Set Screws with Full Dog Point

    Screw Thread
d
    M1.2
    M1.6
    M2
    M2.5
    M3
    (M3.5)
    M4
    M5
    M6
    M8
    M10
    M12



    P
    Pitch
    0.25
    0.35
    0.4
    0.45
    0.5
    0.6
    0.7
    0.8
    1
    1.25
    1.5
    1.75


    d1
    max
    0.12
    0.16
    0.2
    0.25
    0.3
    0.35
    0.4
    0.5
    1.5
    2
    2.5
    3


    n
    Nominal Size
    0.2
    0.25
    0.25
    0.4
    0.4
    0.5
    0.6
    0.8
    1
    1.2
    1.6
    2


    max
    0.4
    0.45
    0.45
    0.6
    0.6
    0.7
    0.8
    1
    1.2
    1.51
    1.91
    2.31


    min
    0.26
    0.31
    0.31
    0.46
    0.46
    0.56
    0.66
    0.86
    1.06
    1.26
    1.66
    2.06


    t
    max
    0.52
    0.74
    0.84
    0.95
    1.05
    1.21
    1.42
    1.63
    2
    2.5
    3
    3.6


    min
    0.4
    0.56
    0.64
    0.72
    0.8
    0.96
    1.12
    1.28
    1.6
    2
    2.4
    2.8


Screw Thread d	M1.2	M1.6	M2	M2.5	M3	(M3.5)	M4	M5	M6	M8	M10	M12
P	Pitch	0.25	0.35	0.4	0.45	0.5	0.6	0.7	0.8	1	1.25	1.5	1.75
d1	max	0.12	0.16	0.2	0.25	0.3	0.35	0.4	0.5	1.5	2	2.5	3
n	Nominal Size	0.2	0.25	0.25	0.4	0.4	0.5	0.6	0.8	1	1.2	1.6	2
max	0.4	0.45	0.45	0.6	0.6	0.7	0.8	1	1.2	1.51	1.91	2.31
min	0.26	0.31	0.31	0.46	0.46	0.56	0.66	0.86	1.06	1.26	1.66	2.06
t	max	0.52	0.74	0.84	0.95	1.05	1.21	1.42	1.63	2	2.5	3	3.6
min	0.4	0.56	0.64	0.72	0.8	0.96	1.12	1.28	1.6	2	2.4	2.8

Equivalent Standard for DIN 553 Slotted Set Screws with Cone Point - GB/T 71

GB/T 71 Hexagon Socket Set Screws with Full Dog Point

    Thread Size
d
    M1.2
    M1.6
    M2
    M2.5
    M3
    (M3.5)
    M4
    M5
    M6
    M8
    M10
    M12



    P
    Pitch
    0.25
    0.35
    0.4
    0.45
    0.5
    0.6
    0.7
    0.8
    1
    1.25
    1.5
    1.75


    d1
    max
    0.12
    0.16
    0.2
    0.25
    0.3
    0.35
    0.4
    0.5
    1.5
    2
    2.5
    3


    n
    Nominal Size
    0.2
    0.25
    0.25
    0.4
    0.4
    0.5
    0.6
    0.8
    1
    1.2
    1.6
    2


    min
    0.26
    0.31
    0.31
    0.46
    0.46
    0.56
    0.66
    0.86
    1.06
    1.26
    1.66
    2.06


    max
    0.4
    0.45
    0.45
    0.6
    0.6
    0.7
    0.8
    1
    1.2
    1.51
    1.91
    2.31


    t
    min
    0.4
    0.56
    0.64
    0.72
    0.8
    0.96
    1.12
    1.28
    1.6
    2
    2.4
    2.8


    max
    0.52
    0.74
    0.84
    0.95
    1.05
    1.21
    1.42
    1.63
    2
    2.5
    3
    3.6


Thread Size d	M1.2	M1.6	M2	M2.5	M3	(M3.5)	M4	M5	M6	M8	M10	M12
P	Pitch	0.25	0.35	0.4	0.45	0.5	0.6	0.7	0.8	1	1.25	1.5	1.75
d1	max	0.12	0.16	0.2	0.25	0.3	0.35	0.4	0.5	1.5	2	2.5	3
n	Nominal Size	0.2	0.25	0.25	0.4	0.4	0.5	0.6	0.8	1	1.2	1.6	2
min	0.26	0.31	0.31	0.46	0.46	0.56	0.66	0.86	1.06	1.26	1.66	2.06
max	0.4	0.45	0.45	0.6	0.6	0.7	0.8	1	1.2	1.51	1.91	2.31
t	min	0.4	0.56	0.64	0.72	0.8	0.96	1.12	1.28	1.6	2	2.4	2.8
max	0.52	0.74	0.84	0.95	1.05	1.21	1.42	1.63	2	2.5	3	3.6
