DIN 980 Lock Nut Carbon Steel Stainless Steel High Quality China Origin Supplier

All-Metal Prevailing Torque Type DIN 980 lock Nuts

DIN 980 lock nuts, also known as all metal lock nut, hexagon nuts with thread lock, prevailing torque lock nuts all metal, prevailing torque self lock nut.

DIN 980 lock nuts contains two kinds of DIN 980V and DIN 980M. DIN 980V is all-metal deformation locking (there are many kinds of deformation, such as mouth deformation, pressure point deformation, etc.). DIN 980M is all-metal riveted steel sheet locking (one end of the nut is riveted with steel sheet included).

[njwa_button id="3060"]

All-Metal Prevailing Torque Type DIN 980 lock Nuts Details

SIZE: M3-M39

MATEAIL: Carbon Steel, Stainless Steel

STANDARD: DIN980V, DIN980M, ISO7042, DIN EN ISO10503, ISO7719

GRADE: 5, 8, 10, A2-70, A4-80

SURFACE TREATMENT: ZP, HDG, BLACK, Dacromet

CUSTOMIZED SUPPORT: YES

All-Metal Prevailing Torque Type DIN 980 lock Nuts Gallery

DIN980V All-Metal Prevailing Torque Type Hex Lock Nuts

304 Stainless Steel DIN980M All-Metal Prevailing Torque Type Hex Lock Nuts

Black DIN980M All-Metal Prevailing Torque Type Hex Lock Nuts

DIN980V All-Metal Prevailing Torque Type Hex lock Nuts Specifications

Thread Size
dM3M4M5M6M7M8M10M12M14M16
PPitchCoarse   thread0.50.70.8111.251.51.7522
Fine thread 1/////111.51.51.5
Fine thread 2//////1.251.25//
damin　34567810121416
max　3.454.65.756.757.758.7510.81315.117.3
dwmin　4.65.96.98.99.611.615.617.420.522.5
emin　6.017.668.7911.0512.1214.3818.921.124.4926.75
hmax=nominal   size　3.74.25.167810121416
min　3.43.94.85.76.57.59111214
mwmin　1.652.22.753.33.854.45.56.67.78.8
smax=nominal   size　5.57810111317192224
min　5.326.787.789.7810.7312.7316.7318.6721.6723.67
　
Thread   Size
dM18M20M22M24M27M30M33M36M39　
PPitchCoarse   thread2.52.52.5333.53.544　
Fine thread 1222222233　
Fine thread 21.51.51.5//////　
damin　182022242730333639　
max　19.521.623.725.929.132.435.638.942.1　
dwmin　24.927.729.533.23842.746.651.155.9　
emin　29.5632.9535.0339.5545.250.8555.3760.7966.44　
hmax=nominal   size　182022242730333639　
min　161820222528313437　
mwmin　9.91112.213.214.816.518.219.821.5　
smax=nominal   size　273032364146505560　
min　26.1629.16313540454953.858.8　

Thread Size d	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16
P	Pitch	Coarse thread	0.5	0.7	0.8	1	1	1.25	1.5	1.75	2	2
Fine thread 1	/	/	/	/	/	1	1	1.5	1.5	1.5
Fine thread 2	/	/	/	/	/	/	1.25	1.25	/	/
da	min		3	4	5	6	7	8	10	12	14	16
max		3.45	4.6	5.75	6.75	7.75	8.75	10.8	13	15.1	17.3
dw	min		4.6	5.9	6.9	8.9	9.6	11.6	15.6	17.4	20.5	22.5
e	min		6.01	7.66	8.79	11.05	12.12	14.38	18.9	21.1	24.49	26.75
h	max=nominal size		3.7	4.2	5.1	6	7	8	10	12	14	16
min		3.4	3.9	4.8	5.7	6.5	7.5	9	11	12	14
mw	min		1.65	2.2	2.75	3.3	3.85	4.4	5.5	6.6	7.7	8.8
s	max=nominal size		5.5	7	8	10	11	13	17	19	22	24
min		5.32	6.78	7.78	9.78	10.73	12.73	16.73	18.67	21.67	23.67

Thread Size d	M18	M20	M22	M24	M27	M30	M33	M36	M39
P	Pitch	Coarse thread	2.5	2.5	2.5	3	3	3.5	3.5	4	4
Fine thread 1	2	2	2	2	2	2	2	3	3
Fine thread 2	1.5	1.5	1.5	/	/	/	/	/	/
da	min		18	20	22	24	27	30	33	36	39
max		19.5	21.6	23.7	25.9	29.1	32.4	35.6	38.9	42.1
dw	min		24.9	27.7	29.5	33.2	38	42.7	46.6	51.1	55.9
e	min		29.56	32.95	35.03	39.55	45.2	50.85	55.37	60.79	66.44
h	max=nominal size		18	20	22	24	27	30	33	36	39
min		16	18	20	22	25	28	31	34	37
mw	min		9.9	11	12.2	13.2	14.8	16.5	18.2	19.8	21.5
s	max=nominal size		27	30	32	36	41	46	50	55	60
min		26.16	29.16	31	35	40	45	49	53.8	58.8

DIN980M All-Metal Prevailing Torque Type Hex lock Nuts Specifications

Screw Thread
dM3M4M5M6M7M8M10M12M14M16
PPitch0.50.70.8111.251.51.7522
Fine thread-----111.51.51.5
Fine thread------1.251.25--
emin6.017.668.7911.0512.1214.3818.921.124.4926.75
hmax=nominal   size3.74.25.167810121416
min3.43.94.85.76.57.59111214
smax=nominal   size5.57810111317192224
min5.326.787.789.7810.7312.7316.7318.6721.6723.67
　
Screw   Thread
dM18M20M22M24M27M30M33M36M39　
PPitch2.52.52.5333.53.544　
Fine thread222222233　
Fine thread1.51.51.5------　
emin29.5632.9535.0339.5545.250.8555.3760.7966.44　
hmax=nominal   size182022242730333639　
min161820222528313437　
smax=nominal   size273032364146505560　
min26.1629.16313540454953.858.8　

Screw Thread d	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16
P	Pitch	0.5	0.7	0.8	1	1	1.25	1.5	1.75	2	2
Fine thread	-	-	-	-	-	1	1	1.5	1.5	1.5
Fine thread	-	-	-	-	-	-	1.25	1.25	-	-
e	min	6.01	7.66	8.79	11.05	12.12	14.38	18.9	21.1	24.49	26.75
h	max=nominal size	3.7	4.2	5.1	6	7	8	10	12	14	16
min	3.4	3.9	4.8	5.7	6.5	7.5	9	11	12	14
s	max=nominal size	5.5	7	8	10	11	13	17	19	22	24
min	5.32	6.78	7.78	9.78	10.73	12.73	16.73	18.67	21.67	23.67

Screw Thread d	M18	M20	M22	M24	M27	M30	M33	M36	M39
P	Pitch	2.5	2.5	2.5	3	3	3.5	3.5	4	4
Fine thread	2	2	2	2	2	2	2	3	3
Fine thread	1.5	1.5	1.5	-	-	-	-	-	-
e	min	29.56	32.95	35.03	39.55	45.2	50.85	55.37	60.79	66.44
h	max=nominal size	18	20	22	24	27	30	33	36	39
min	16	18	20	22	25	28	31	34	37
s	max=nominal size	27	30	32	36	41	46	50	55	60
min	26.16	29.16	31	35	40	45	49	53.8	58.8
