DIN982 Nylon Lock Nuts Carbon Steel Stainless Steel Best Quality Competitive Price

Nylon Lock Nut Introduction

Nylon Lock Nuts, also known as Nylon Nut, Hex Nylon Insert Nuts, Self-locking hexagon nut. DIN982 nylon lock nut is thicker and DIN985 nylon lock nut is thinner. The inside diameter of the non-metallic locking ring is smaller than the pitch diameter of the nut thread.

When the bolt screwed into the Nylon Lock Nuts, the nylon locking ring is destroyed and the gap between the thread fit is filled, the nylon and the thread are completely extruded, and the extruded nylon produces a large rebound force on the bolt, which increases the friction , so that the bolts are not easy to loosen and play the role of anti-loosening locking.

Two silver stainless steel nylon lock nuts

Nylon Lock Nut Details

SIZE: M3-M48

MATEAIL: Carbon Steel, Stainless Steel

STANDARD: DIN982, DIN985, ISO7040

GRADE: 5, 8, 10

SURFACE TREATMENT: ZP, HDG, BLACK, Dacromet

CUSTOMIZED SUPPORT: YES

DIN982 Nylon Lock Nut Specifications

    Screw Thread
d
    M5
    M6
    M7
    M8
    M10
    M12
    M14
    M16
    M18
    M20
    M22
    M24



    P
    Pitch
    Coarse thread
    0.8
    1
    1
    1.25
    1.5
    1.75
    2
    2
    2.5
    2.5
    2.5
    3


    Fine thread 1
    /
    /
    /
    1
    1
    1.5
    1.5
    1.5
    2
    2
    2
    2


    Fine thread 2
    /
    /
    /
    /
    1.25
    1.25
    /
    /
    1.5
    1.5
    1.5
    /


    da
    min
    　
    5
    6
    7
    8
    10
    12
    14
    16
    18
    20
    22
    24


    max
    　
    5.75
    6.75
    7.75
    8.75
    10.8
    13
    15.1
    17.3
    19.5
    21.6
    23.7
    25.9


    dw
    min
    　
    6.9
    8.9
    9.6
    11.6
    15.6
    17.4
    20.5
    22.5
    24.9
    27.7
    29.5
    33.2


    e
    min
    　
    8.79
    11.05
    12.12
    14.38
    18.9
    21.1
    24.49
    26.75
    29.56
    32.95
    35.03
    39.55


    h
    max=nominal   size
    　
    6.3
    8
    8.5
    9.5
    11.5
    14
    16
    18
    20
    22
    25
    28


    min
    　
    6
    7.7
    8.2
    9.14
    11.14
    13.64
    15.3
    17.3
    19.16
    20.7
    23.7
    26.7


    m
    min
    　
    4.4
    4.9
    6.14
    6.44
    8.04
    10.37
    12.1
    14.1
    15.1
    16.9
    18.1
    20.2


    mw
    min
    　
    3.52
    3.92
    4.91
    5.15
    6.43
    8.3
    9.68
    11.28
    12.08
    13.52
    14.48
    16.16


    s
    max=nominal   size
    　
    8
    10
    11
    13
    17
    19
    22
    24
    27
    30
    32
    36


    min
    　
    7.78
    9.78
    10.73
    12.73
    16.73
    18.67
    21.67
    23.67
    26.16
    29.16
    31
    35


Screw Thread d	M5	M6	M7	M8	M10	M12	M14	M16	M18	M20	M22	M24
P	Pitch	Coarse thread	0.8	1	1	1.25	1.5	1.75	2	2	2.5	2.5	2.5	3
Fine thread 1	/	/	/	1	1	1.5	1.5	1.5	2	2	2	2
Fine thread 2	/	/	/	/	1.25	1.25	/	/	1.5	1.5	1.5	/
da	min		5	6	7	8	10	12	14	16	18	20	22	24
max		5.75	6.75	7.75	8.75	10.8	13	15.1	17.3	19.5	21.6	23.7	25.9
dw	min		6.9	8.9	9.6	11.6	15.6	17.4	20.5	22.5	24.9	27.7	29.5	33.2
e	min		8.79	11.05	12.12	14.38	18.9	21.1	24.49	26.75	29.56	32.95	35.03	39.55
h	max=nominal size		6.3	8	8.5	9.5	11.5	14	16	18	20	22	25	28
min		6	7.7	8.2	9.14	11.14	13.64	15.3	17.3	19.16	20.7	23.7	26.7
m	min		4.4	4.9	6.14	6.44	8.04	10.37	12.1	14.1	15.1	16.9	18.1	20.2
mw	min		3.52	3.92	4.91	5.15	6.43	8.3	9.68	11.28	12.08	13.52	14.48	16.16
s	max=nominal size		8	10	11	13	17	19	22	24	27	30	32	36
min		7.78	9.78	10.73	12.73	16.73	18.67	21.67	23.67	26.16	29.16	31	35

DIN985 Nylon Lock Nut Specifications

    Thread Size
d
    M3
    M4
    M5
    M6
    M7
    M8
    M10
    M12
    M14
    M16
    M18



    P
    Pitch
    Coarse   thread
    0.5
    0.7
    0.8
    1
    1
    1.25
    1.5
    1.75
    2
    2
    2.5


    Fine thread 1
    /
    /
    /
    /
    /
    1
    1
    1.5
    1.5
    1.5
    2


    Fine thread 2
    /
    /
    /
    /
    /
    /
    1.25
    1.25
    /
    /
    1.5


    da
    min
    　
    3
    4
    5
    6
    7
    8
    10
    12
    14
    16
    18


    max
    　
    3.45
    4.6
    5.75
    6.75
    7.75
    8.75
    10.8
    13
    15.1
    17.3
    19.5


    dw
    min
    　
    4.6
    5.9
    6.9
    8.9
    9.6
    11.6
    15.6
    17.4
    20.5
    22.5
    24.9


    e
    min
    　
    6.01
    7.66
    8.79
    11.05
    12.12
    14.38
    18.9
    21.1
    24.49
    26.75
    29.56


    h
    max=nominal   size
    　
    4
    5
    5
    6
    7.5
    8
    10
    12
    14
    16
    18.5


    min
    　
    3.7
    4.7
    4.7
    5.7
    7.14
    7.64
    9.64
    11.57
    13.3
    15.3
    17.66


    m
    min
    　
    2.4
    2.9
    3.2
    4
    4.7
    5.5
    6.5
    8
    9.5
    10.5
    13


    mw
    min
    　
    1.65
    2.2
    2.75
    3.3
    3.85
    4.4
    5.5
    6.6
    7.7
    8.8
    9.9


    s
    max=nominal   size
    　
    5.5
    7
    8
    10
    11
    13
    17
    19
    22
    24
    27


    min
    　
    5.32
    6.78
    7.78
    9.78
    10.73
    12.73
    16.73
    18.67
    21.67
    23.67
    26.16


    　


    Thread Size
d
    M20
    M22
    M24
    M27
    M30
    M33
    M36
    M39
    M42
    M45
    M48


    P
    Pitch
    Coarse   thread
    2.5
    2.5
    3
    3
    3.5
    3.5
    4
    4
    4.5
    4.5
    5


    Fine thread 1
    2
    2
    2
    2
    2
    2
    3
    3
    3
    3
    3


    Fine thread 2
    1.5
    1.5
    /
    /
    /
    /
    /
    /
    /
    /
    /


    da
    min
    　
    20
    22
    24
    27
    30
    33
    36
    39
    42
    45
    48


    max
    　
    21.6
    23.7
    25.9
    29.1
    32.4
    35.6
    38.9
    42.1
    45.4
    48.6
    51.8


    dw
    min
    　
    27.7
    29.5
    33.2
    38
    42.7
    46.6
    51.1
    55.9
    60.6
    64.7
    69.4


    e
    min
    　
    32.95
    35.03
    39.55
    45.2
    50.85
    55.37
    60.79
    66.44
    72.09
    76.95
    82.6


    h
    max=nominal   size
    　
    20
    22
    24
    27
    30
    33
    36
    39
    42
    45
    48


    min
    　
    18.7
    20.7
    22.7
    25.7
    28.7
    31.4
    34.4
    37.4
    40.4
    43.4
    46.4


    m
    min
    　
    14
    15
    15
    17
    19
    22
    25
    27
    29
    32
    36


    mw
    min
    　
    11
    12.2
    13.2
    14.8
    16.5
    18.2
    19.8
    21.5
    23.1
    24.8
    26.5


    s
    max=nominal   size
    　
    30
    32
    36
    41
    46
    50
    55
    60
    65
    70
    75


    min
    　
    29.16
    31
    35
    40
    45
    49
    53.8
    58.8
    63.8
    68.1
    73.1


Thread Size d	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16	M18
P	Pitch	Coarse thread	0.5	0.7	0.8	1	1	1.25	1.5	1.75	2	2	2.5
Fine thread 1	/	/	/	/	/	1	1	1.5	1.5	1.5	2
Fine thread 2	/	/	/	/	/	/	1.25	1.25	/	/	1.5
da	min		3	4	5	6	7	8	10	12	14	16	18
max		3.45	4.6	5.75	6.75	7.75	8.75	10.8	13	15.1	17.3	19.5
dw	min		4.6	5.9	6.9	8.9	9.6	11.6	15.6	17.4	20.5	22.5	24.9
e	min		6.01	7.66	8.79	11.05	12.12	14.38	18.9	21.1	24.49	26.75	29.56
h	max=nominal size		4	5	5	6	7.5	8	10	12	14	16	18.5
min		3.7	4.7	4.7	5.7	7.14	7.64	9.64	11.57	13.3	15.3	17.66
m	min		2.4	2.9	3.2	4	4.7	5.5	6.5	8	9.5	10.5	13
mw	min		1.65	2.2	2.75	3.3	3.85	4.4	5.5	6.6	7.7	8.8	9.9
s	max=nominal size		5.5	7	8	10	11	13	17	19	22	24	27
min		5.32	6.78	7.78	9.78	10.73	12.73	16.73	18.67	21.67	23.67	26.16

Thread Size d	M20	M22	M24	M27	M30	M33	M36	M39	M42	M45	M48
P	Pitch	Coarse thread	2.5	2.5	3	3	3.5	3.5	4	4	4.5	4.5	5
Fine thread 1	2	2	2	2	2	2	3	3	3	3	3
Fine thread 2	1.5	1.5	/	/	/	/	/	/	/	/	/
da	min		20	22	24	27	30	33	36	39	42	45	48
max		21.6	23.7	25.9	29.1	32.4	35.6	38.9	42.1	45.4	48.6	51.8
dw	min		27.7	29.5	33.2	38	42.7	46.6	51.1	55.9	60.6	64.7	69.4
e	min		32.95	35.03	39.55	45.2	50.85	55.37	60.79	66.44	72.09	76.95	82.6
h	max=nominal size		20	22	24	27	30	33	36	39	42	45	48
min		18.7	20.7	22.7	25.7	28.7	31.4	34.4	37.4	40.4	43.4	46.4
m	min		14	15	15	17	19	22	25	27	29	32	36
mw	min		11	12.2	13.2	14.8	16.5	18.2	19.8	21.5	23.1	24.8	26.5
s	max=nominal size		30	32	36	41	46	50	55	60	65	70	75
min		29.16	31	35	40	45	49	53.8	58.8	63.8	68.1	73.1
