Welding Studs Shear Connector High Quality China Origin Supplier ISO13918 SD

Product Introduction

Arc Stud Welding - Shear Connector - Type SD, also known as cheese head studs for arc stud welding, seismic wedge anchors, shear studs, etc. It belongs to high strength fasteners.

Shear connectors have standards such as ISO, JIS, GB, ANSI/AWS. Commonly used standards for shear connectors include ISO13918 (SD), JIS B 1198, GB/T10433, ANSI/AWSD 1.1, ANSI/AWSD 1.6 and so on.

Arc Stud Welding - Shear Connector - Type SD is suitable for steel structure workshops, roads and railways, airports, bridges, pipe rack supports, power stations, new energy facilities and other various steel structure construction projects. The common specifications of Arc Stud Welding - Shear Connector - Type SD are M16, M19, M22, M25.

[njwa_button id="3060"]

Product Details

SIZE: M10-M25

MATEAIL: ML15, ML15AL, Q195

STANDARD: GB/T10433, BS EN ISO13918, JIS B 1198, ANSI/AWSD 1.1, ANSI/AWSD 1.6, BS5400

GRADE: 12.9

SURFACE TREATMENT: ZP, HDG, BLACK, Dacromet

CUSTOMIZED SUPPORT: YES

ISO13918 Shear Connector Type SD Specifications

    Screw Thread
d
    9.5
    10
    12.7
    13
    16
    19
    22
    25
    25.4



    d
    max
    　
    9.9
    10.4
    13.1
    13.4
    16.4
    19.4
    22.4
    25.4
    25.8


    min
    　
    9.1
    9.6
    12.3
    12.6
    15.6
    18.6
    21.6
    24.6
    25


    dc
    Nominal   Size
    　
    19
    19
    25
    25
    32
    32
    35
    40
    41


    max
    　
    19.3
    19.3
    25.3
    25.3
    32.3
    32.3
    35.3
    40.3
    41.3


    min
    　
    18.7
    18.7
    24.7
    24.7
    31.7
    31.7
    34.7
    39.7
    40.7


    d1
    13
    13
    17
    17
    21
    23
    29
    31
    31


    h3
    Nominal   Size
    　
    7
    7
    8
    8
    8
    10
    10
    12
    12


    max
    　
    8
    8
    9
    9
    9
    11
    11
    13
    13


    min
    　
    6.5
    6.5
    7.5
    7.5
    7.5
    9.5
    9.5
    11.5
    11.5


    h
    2.5
    2.5
    3
    3
    4.5
    6
    6
    7
    7


    L1
    ±1.5
    　
    L2   +3
    L2 +3
    L2 +3
    L2 +3
    L2 +4
    L2 +4.5
    L2 +5
    L2 +5.5
    L2 +5.5


Screw Thread d	9.5	10	12.7	13	16	19	22	25	25.4
d	max		9.9	10.4	13.1	13.4	16.4	19.4	22.4	25.4	25.8
min		9.1	9.6	12.3	12.6	15.6	18.6	21.6	24.6	25
dc	Nominal Size		19	19	25	25	32	32	35	40	41
max		19.3	19.3	25.3	25.3	32.3	32.3	35.3	40.3	41.3
min		18.7	18.7	24.7	24.7	31.7	31.7	34.7	39.7	40.7
d1	13	13	17	17	21	23	29	31	31
h3	Nominal Size		7	7	8	8	8	10	10	12	12
max		8	8	9	9	9	11	11	13	13
min		6.5	6.5	7.5	7.5	7.5	9.5	9.5	11.5	11.5
h	2.5	2.5	3	3	4.5	6	6	7	7
L1	±1.5		L2 +3	L2 +3	L2 +3	L2 +3	L2 +4	L2 +4.5	L2 +5	L2 +5.5	L2 +5.5
