Hexagon Slotted Nuts

Slotted nuts mainly refer to Hexagon Slotted Nuts. Slotted Nuts are characterized by several slots machined above the hex nut. Slotted nut is available in carbon steel, stainless steel, and other materials.

Slotted nuts has DIN, ANSI, JIS, IFI, GB, EN, ISO, BSW and other standards. Commonly used standards are DIN935-1 and DIN935-3. The specification of DIN935-3 Slotted nuts is M12-M33. The specification of DIN935-1 Slotted nuts is M4-M48.

Hexagon Slotted Nuts Details

SIZE: M12-M33

MATEAIL: Carbon Steel, Stainless Steel

STANDARD: DIN935-3, DIN935-1

GRADE: 8, 10, 12

SURFACE TREATMENT: ZP, HDG, BLACK, Dacromet

CUSTOMIZED SUPPORT: YES

DIN935-1 Hexagon Slotted Nuts Specifications

    Thread Size
d
    M4
    M5
    M6
    (M7)
    M8
    M10
    M12
    (M14)
    M16
    (M18)
    M20
    (M22)
    M24
    (M27)
    M30
    (M33)



    P
    Pitch   (Coarse thread)
    　
    0.7
    0.8
    1
    1
    1.25
    1.5
    1.75
    2
    2
    2.5
    2.5
    2.5
    3
    3
    3.5
    3.5


    Fine thread-1
    　
    -
    -
    -
    -
    1
    1.25
    1.5
    1.5
    1.5
    1.5
    2
    1.5
    2
    2
    2
    2


    Fine thread-2
    　
    -
    -
    -
    -
    -
    1
    1.25
    -
    -
    2
    1.5
    2
    -
    -
    -
    -


    da
    max
    　
    4.6
    5.75
    6.75
    7.75
    8.75
    10.8
    13
    15.1
    17.3
    19.5
    21.6
    23.8
    25.9
    29.2
    32.4
    35.6


    min
    　
    4
    5
    6
    7
    8
    10
    12
    14
    16
    18
    20
    22
    24
    27
    30
    33


    de
    max
    　
    /
    /
    /
    /
    /
    /
    16
    18
    22
    25
    28
    32
    34
    38
    42
    46


    min
    　
    /
    /
    /
    /
    /
    /
    15.57
    17.57
    21.48
    24.3
    27.3
    31
    33
    37
    41
    45


    dw
    min
    　
    5.9
    6.9
    8.9
    9.5
    11.6
    14.6
    16.6
    19.6
    22.5
    24.9
    27.7
    31.4
    33.2
    38
    42.7
    46.6


    e
    min
    　
    7.66
    8.79
    11.05
    12.12
    14.38
    17.77
    20.03
    23.35
    26.75
    29.56
    32.95
    37.29
    39.55
    45.2
    50.85
    55.37


    m
    max=nominal   size
    　
    5
    6
    7.5
    8
    9.5
    12
    15
    16
    19
    21
    22
    26
    27
    30
    33
    35


    min
    　
    4.7
    5.7
    7.14
    7.64
    9.14
    11.57
    14.57
    15.57
    18.48
    20.16
    21.16
    25.16
    26.16
    29.16
    32
    34


    w
    max
    　
    3.2
    4
    5
    5.5
    6.5
    8
    10
    11
    13
    15
    16
    18
    19
    22
    24
    26


    min
    　
    2.9
    3.7
    4.7
    5.2
    6.14
    7.64
    9.64
    10.57
    12.57
    14.57
    15.57
    17.57
    18.48
    21.48
    23.48
    25.48


    m1
    min
    　
    2.3
    3
    3.8
    4.2
    4.9
    6.1
    7.7
    8.2
    9.8
    11.2
    11.9
    13.5
    14.2
    16.6
    18.2
    19.8


    n
    max
    　
    1.45
    1.65
    2.25
    2.25
    2.75
    3.05
    3.8
    3.8
    4.8
    4.8
    4.8
    5.8
    5.8
    5.8
    7.36
    7.36


    min
    　
    1.2
    1.4
    2
    2
    2.5
    2.8
    3.5
    3.5
    4.5
    4.5
    4.5
    5.5
    5.5
    5.5
    7
    7


    s
    max=nominal   size
    　
    7
    8
    10
    11
    13
    16
    18
    21
    24
    27
    30
    34
    36
    41
    46
    50


    min
    　
    6.78
    7.78
    9.78
    10.73
    12.73
    15.73
    17.73
    20.67
    23.67
    26.16
    29.16
    33
    35
    40
    45
    49


    Series ②
    Split   Pin as in DIN EN ISO 1234
    　
    1x10
    1.2x12
    1.6x14
    1.6x14
    2x16
    2.5x20
    3.2x22
    3.2x25
    4x28
    4x32
    4x36
    5x36
    5x40
    5x45
    6.3x50
    6.3x56


    　


    Thread   Size
     d
    M36
    (M39)
    M42
    (M45)
    M48
    (M52)
    M56
    (M60)
    M64
    (M68)
    M72
    (M76)
    M80
    (M85)
    M90
    M100


    P
    Pitch   (Coarse thread)
    　
    4
    4
    4.5
    4.5
    5
    5
    5.5
    5.5
    6
    6
    -
    -
    -
    -
    -
    -


    Fine thread-1
    　
    3
    3
    3
    3
    3
    3
    4
    4
    4
    4
    6
    6
    6
    6
    6
    6


    Fine thread-2
    　
    -
    -
    -
    -
    -
    -
    -
    -
    -
    -
    4
    4
    4
    4
    4
    4


    da
    max
    　
    38.9
    42.1
    45.4
    48.6
    51.8
    56.2
    61
    64.8
    69.1
    73.4
    77.8
    82.1
    86.4
    91.8
    97.2
    108


    min
    　
    36
    39
    42
    45
    48
    52
    56
    60
    64
    68
    72
    76
    80
    85
    90
    100


    de
    max
    　
    50
    55
    58
    62
    65
    70
    75
    80
    85
    90
    95
    100
    105
    110
    120
    130


    min
    　
    49
    53.8
    56.8
    60.8
    63.8
    68.8
    73.8
    78.8
    83.6
    88.6
    93.6
    98.6
    103.6
    108.6
    118.6
    128.4


    dw
    min
    　
    51.1
    55.9
    60.6
    64.7
    69.4
    74.2
    78.7
    83.4
    88.2
    92.9
    97.7
    102.4
    107.2
    111.9
    121.1
    135.4


    e
    min
    　
    60.79
    66.44
    71.3
    76.95
    82.6
    88.25
    93.56
    99.21
    104.86
    110.51
    116.16
    121.81
    127.46
    133.11
    144.08
    161.02


    m
    max=nominal   size
    　
    38
    40
    46
    48
    50
    54
    57
    63
    66
    69
    73
    76
    79
    88
    92
    100


    min
    　
    37
    39
    45
    47
    49
    52.8
    55.8
    61.8
    64.8
    67.8
    71.8
    74.8
    77.8
    86.6
    90.6
    98.6


    w
    max
    　
    29
    31
    34
    36
    38
    42
    45
    48
    51
    54
    58
    61
    64
    68
    72
    80


    min
    　
    28.48
    30.28
    33.38
    35.38
    37.38
    41.38
    44.38
    47.38
    50.26
    53.26
    57.26
    60.26
    63.26
    67.26
    71.26
    79.26


    m1
    min
    　
    21.9
    23.5
    25.9
    27.5
    29.1
    32.3
    34.7
    37.1
    39.3
    41.7
    44.9
    47.3
    49.7
    52.9
    56.1
    62.5


    n
    max
    　
    7.36
    7.36
    9.36
    9.36
    9.36
    9.36
    9.36
    11.43
    11.43
    11.43
    11.43
    11.43
    11.43
    14.43
    14.43
    14.43


    min
    　
    7
    7
    9
    9
    9
    9
    9
    11
    11
    11
    11
    11
    11
    14
    14
    14


    s
    max=nominal   size
    　
    55
    60
    65
    70
    75
    80
    85
    90
    95
    100
    105
    110
    115
    120
    130
    145


    min
    　
    53.8
    58.8
    63.1
    68.1
    73.1
    78.1
    82.8
    87.8
    92.8
    97.8
    102.8
    107.8
    112.8
    117.8
    127.5
    142.5


    Series ②
    Split   Pin as in DIN EN ISO 1234
    　
    6.3x63
    6.3x71
    8x71
    8x80
    8x80
    8x90
    8x100
    10x100
    10x100
    10x112
    10x112
    10x125
    10x140
    10x140
    10x140
    10x160


Thread Size d	M4	M5	M6	(M7)	M8	M10	M12	(M14)	M16	(M18)	M20	(M22)	M24	(M27)	M30	(M33)
P	Pitch (Coarse thread)		0.7	0.8	1	1	1.25	1.5	1.75	2	2	2.5	2.5	2.5	3	3	3.5	3.5
Fine thread-1		-	-	-	-	1	1.25	1.5	1.5	1.5	1.5	2	1.5	2	2	2	2
Fine thread-2		-	-	-	-	-	1	1.25	-	-	2	1.5	2	-	-	-	-
da	max		4.6	5.75	6.75	7.75	8.75	10.8	13	15.1	17.3	19.5	21.6	23.8	25.9	29.2	32.4	35.6
min		4	5	6	7	8	10	12	14	16	18	20	22	24	27	30	33
de	max		/	/	/	/	/	/	16	18	22	25	28	32	34	38	42	46
min		/	/	/	/	/	/	15.57	17.57	21.48	24.3	27.3	31	33	37	41	45
dw	min		5.9	6.9	8.9	9.5	11.6	14.6	16.6	19.6	22.5	24.9	27.7	31.4	33.2	38	42.7	46.6
e	min		7.66	8.79	11.05	12.12	14.38	17.77	20.03	23.35	26.75	29.56	32.95	37.29	39.55	45.2	50.85	55.37
m	max=nominal size		5	6	7.5	8	9.5	12	15	16	19	21	22	26	27	30	33	35
min		4.7	5.7	7.14	7.64	9.14	11.57	14.57	15.57	18.48	20.16	21.16	25.16	26.16	29.16	32	34
w	max		3.2	4	5	5.5	6.5	8	10	11	13	15	16	18	19	22	24	26
min		2.9	3.7	4.7	5.2	6.14	7.64	9.64	10.57	12.57	14.57	15.57	17.57	18.48	21.48	23.48	25.48
m1	min		2.3	3	3.8	4.2	4.9	6.1	7.7	8.2	9.8	11.2	11.9	13.5	14.2	16.6	18.2	19.8
n	max		1.45	1.65	2.25	2.25	2.75	3.05	3.8	3.8	4.8	4.8	4.8	5.8	5.8	5.8	7.36	7.36
min		1.2	1.4	2	2	2.5	2.8	3.5	3.5	4.5	4.5	4.5	5.5	5.5	5.5	7	7
s	max=nominal size		7	8	10	11	13	16	18	21	24	27	30	34	36	41	46	50
min		6.78	7.78	9.78	10.73	12.73	15.73	17.73	20.67	23.67	26.16	29.16	33	35	40	45	49
Series ②	Split Pin as in DIN EN ISO 1234		1x10	1.2x12	1.6x14	1.6x14	2x16	2.5x20	3.2x22	3.2x25	4x28	4x32	4x36	5x36	5x40	5x45	6.3x50	6.3x56

Thread Size d	M36	(M39)	M42	(M45)	M48	(M52)	M56	(M60)	M64	(M68)	M72	(M76)	M80	(M85)	M90	M100
P	Pitch (Coarse thread)		4	4	4.5	4.5	5	5	5.5	5.5	6	6	-	-	-	-	-	-
Fine thread-1		3	3	3	3	3	3	4	4	4	4	6	6	6	6	6	6
Fine thread-2		-	-	-	-	-	-	-	-	-	-	4	4	4	4	4	4
da	max		38.9	42.1	45.4	48.6	51.8	56.2	61	64.8	69.1	73.4	77.8	82.1	86.4	91.8	97.2	108
min		36	39	42	45	48	52	56	60	64	68	72	76	80	85	90	100
de	max		50	55	58	62	65	70	75	80	85	90	95	100	105	110	120	130
min		49	53.8	56.8	60.8	63.8	68.8	73.8	78.8	83.6	88.6	93.6	98.6	103.6	108.6	118.6	128.4
dw	min		51.1	55.9	60.6	64.7	69.4	74.2	78.7	83.4	88.2	92.9	97.7	102.4	107.2	111.9	121.1	135.4
e	min		60.79	66.44	71.3	76.95	82.6	88.25	93.56	99.21	104.86	110.51	116.16	121.81	127.46	133.11	144.08	161.02
m	max=nominal size		38	40	46	48	50	54	57	63	66	69	73	76	79	88	92	100
min		37	39	45	47	49	52.8	55.8	61.8	64.8	67.8	71.8	74.8	77.8	86.6	90.6	98.6
w	max		29	31	34	36	38	42	45	48	51	54	58	61	64	68	72	80
min		28.48	30.28	33.38	35.38	37.38	41.38	44.38	47.38	50.26	53.26	57.26	60.26	63.26	67.26	71.26	79.26
m1	min		21.9	23.5	25.9	27.5	29.1	32.3	34.7	37.1	39.3	41.7	44.9	47.3	49.7	52.9	56.1	62.5
n	max		7.36	7.36	9.36	9.36	9.36	9.36	9.36	11.43	11.43	11.43	11.43	11.43	11.43	14.43	14.43	14.43
min		7	7	9	9	9	9	9	11	11	11	11	11	11	14	14	14
s	max=nominal size		55	60	65	70	75	80	85	90	95	100	105	110	115	120	130	145
min		53.8	58.8	63.1	68.1	73.1	78.1	82.8	87.8	92.8	97.8	102.8	107.8	112.8	117.8	127.5	142.5
Series ②	Split Pin as in DIN EN ISO 1234		6.3x63	6.3x71	8x71	8x80	8x80	8x90	8x100	10x100	10x100	10x112	10x112	10x125	10x140	10x140	10x140	10x160

DIN935-3 Hexagon Slotted Nuts Specifications

    Thread Size
d
    M12
    M16
    M20
    M24
    (M27)
    M30
    (M33)



    P
    Pitch
    　
    1.75
    2
    2.5
    3
    3
    3.5
    3.5


    da
    min
    　
    12
    16
    20
    24
    27
    30
    33


    max
    　
    13
    17.3
    21.6
    25.9
    29.2
    32.4
    35.6


    dw
    min
    　
    16.1
    21.7
    27.7
    33.2
    38
    42.7
    46.6


    e
    min
    　
    19.85
    26.17
    32.95
    39.55
    45.2
    50.85
    55.37


    m
    max=nominal   size
    　
    15
    19
    22
    27
    30
    33
    35


    min
    　
    13.2
    16.9
    19.9
    24.9
    27.9
    30.5
    32.5


    M1
    min
    　
    10.6
    13.5
    15.9
    19.9
    22.3
    24.4
    26


    n
    min
    　
    3.5
    4.5
    4.5
    5.5
    5.5
    7
    7


    max
    　
    3.98
    4.98
    4.98
    5.98
    5.98
    7.58
    7.58


    s
    max=nominal   size
    　
    18
    24
    30
    36
    41
    46
    50


    min
    　
    17.57
    23.16
    29.16
    35
    40
    45
    49


    w
    min
    　
    9.48
    12.3
    15.3
    18.16
    21.16
    23.16
    25.16


    max
    　
    10
    13
    16
    19
    22
    24
    26


    Series
    Splint   pins (ISO 1234)
    　
    3.2   × 22
    4   × 28
    4   × 36
    5   × 40
    5   × 45
    6.3   × 50
    6.3   × 56


Thread Size d	M12	M16	M20	M24	(M27)	M30	(M33)
P	Pitch		1.75	2	2.5	3	3	3.5	3.5
da	min		12	16	20	24	27	30	33
max		13	17.3	21.6	25.9	29.2	32.4	35.6
dw	min		16.1	21.7	27.7	33.2	38	42.7	46.6
e	min		19.85	26.17	32.95	39.55	45.2	50.85	55.37
m	max=nominal size		15	19	22	27	30	33	35
min		13.2	16.9	19.9	24.9	27.9	30.5	32.5
M1	min		10.6	13.5	15.9	19.9	22.3	24.4	26
n	min		3.5	4.5	4.5	5.5	5.5	7	7
max		3.98	4.98	4.98	5.98	5.98	7.58	7.58
s	max=nominal size		18	24	30	36	41	46	50
min		17.57	23.16	29.16	35	40	45	49
w	min		9.48	12.3	15.3	18.16	21.16	23.16	25.16
max		10	13	16	19	22	24	26
Series	Splint pins (ISO 1234)		3.2 × 22	4 × 28	4 × 36	5 × 40	5 × 45	6.3 × 50	6.3 × 56
