Rivet Nut Carbon Steel Stainless Steel China Origin Manufacturer M4 M5 M6

Product Introduction

Rivet nuts, also called rivnuts, are fasteners used to create threaded holes in materials that can only be accessed from one side. It consists of a cylinder with an internal threaded hole and a flange on one end.

When installing it, you need to use installation tools to fold its body, allowing it to expand and clamp the material from the inside. A strong threaded connection is created, allowing screws or bolts to be used to connect other components.

It is typically used in applications where traditional nut and bolt assemblies do not have access to the backside of the material, such as thin sheet metal or plastic.They provide a strong, reliable and vibration-resistant connection.

[njwa_button id="3060"]

Rivet Nut Details

SIZE: M3-M12

MATEAIL: Carbon Steel, Stainless Steel

STANDARD: GB/T 17880

GRADE: 4.8, 8.8, 10.9, 12.9

SURFACE TREATMENT: Galvanized

CUSTOMIZED SUPPORT: YES

Product Specifications

Flat Head Knurled Body Rivet Nut

ThreadT(GRIP RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
 -0.1BKL
M30.5-1.56.05.04.98.00.810
M40.5-2.0
2.0-3.56.06.05.99.00.810.5
12.0
M50.5-2.5
2.5-5.07.5
8.57.06.910.01.013.0
16.5
M60.5-3.0
3.0-5.59.2
10.59.08.912.30(13.0)1.315.5
19.5
M81.0-3.5
3.5-6.011.511.010.914.5(16.0)1.518.5
21.0
M101.0-4.0
4.0-6.513.513.012.917.0(19.0)1.721.5
24.0
M121.0-4.0
4.0-6.513.5
14.015.014.918.01.722.0
25.0
M101.0-3.511.012.011.916.01.619.0
M121.0-4.0
3.5-6.015.0
16.016.015.922.02.025.0
28.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M3	0.5-1.5	6.0	5.0	4.9	8.0	0.8	10
M4	0.5-2.0 2.0-3.5	6.0	6.0	5.9	9.0	0.8	10.5 12.0
M5	0.5-2.5 2.5-5.0	7.5 8.5	7.0	6.9	10.0	1.0	13.0 16.5
M6	0.5-3.0 3.0-5.5	9.2 10.5	9.0	8.9	12.30(13.0)	1.3	15.5 19.5
M8	1.0-3.5 3.5-6.0	11.5	11.0	10.9	14.5(16.0)	1.5	18.5 21.0
M10	1.0-4.0 4.0-6.5	13.5	13.0	12.9	17.0(19.0)	1.7	21.5 24.0
M12	1.0-4.0 4.0-6.5	13.5 14.0	15.0	14.9	18.0	1.7	22.0 25.0
M10	1.0-3.5	11.0	12.0	11.9	16.0	1.6	19.0
M12	1.0-4.0 3.5-6.0	15.0 16.0	16.0	15.9	22.0	2.0	25.0 28.0

Product Specifications

Flat Head Semi Hex Body Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M40.5-2.06.56.05.99.00.811.0
M50.5-2.58.07.06.910.01.013.0
M60.5-3.08.59.08.912.71.3515.0
M81.0-3.510.511.010.916.01.518.0
M101.0-3.512.513.012.918.01.721.0
M121.0-4.014.015.014.920.01.723.0
M101.0-3.511.012.011.917.01.619.0
M122.0-5.016.516.015.923.02.227.5

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	0.5-2.0	6.5	6.0	5.9	9.0	0.8	11.0
M5	0.5-2.5	8.0	7.0	6.9	10.0	1.0	13.0
M6	0.5-3.0	8.5	9.0	8.9	12.7	1.35	15.0
M8	1.0-3.5	10.5	11.0	10.9	16.0	1.5	18.0
M10	1.0-3.5	12.5	13.0	12.9	18.0	1.7	21.0
M12	1.0-4.0	14.0	15.0	14.9	20.0	1.7	23.0
M10	1.0-3.5	11.0	12.0	11.9	17.0	1.6	19.0
M12	2.0-5.0	16.5	16.0	15.9	23.0	2.2	27.5

Product Specifications

Reduce Head Knurled Body Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0. 1
0D
+0.07
-0.1BKL
M30.5-2.06.25.04.96.00.59.0
M40.5-2.0
2.0-4.07.06.05.97.00.511.2
13.0
M50.5-2.0
     2.0-4.07.07.06.98.00.511.5
13.0
M60.5-2.5
2.5-5.08.59.08.910.00.614.0
16.0
M80.5-3.0
3.0-5.010.011.010.912.00.6516.5
18.5
M101.0-3.5
3.5-6.012.513.012.914.00.719.5
22.0
M101.0-3.512.512.011.913.00.719.5
M121.0-4.016.216.015.917.60.7524.2

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0. 1 0	D +0.07 -0.1	B	K	L
M3	0.5-2.0	6.2	5.0	4.9	6.0	0.5	9.0
M4	0.5-2.0 2.0-4.0	7.0	6.0	5.9	7.0	0.5	11.2 13.0
M5	0.5-2.0 2.0-4.0	7.0	7.0	6.9	8.0	0.5	11.5 13.0
M6	0.5-2.5 2.5-5.0	8.5	9.0	8.9	10.0	0.6	14.0 16.0
M8	0.5-3.0 3.0-5.0	10.0	11.0	10.9	12.0	0.65	16.5 18.5
M10	1.0-3.5 3.5-6.0	12.5	13.0	12.9	14.0	0.7	19.5 22.0
M10	1.0-3.5	12.5	12.0	11.9	13.0	0.7	19.5
M12	1.0-4.0	16.2	16.0	15.9	17.6	0.75	24.2

Product Specifications

Reduce Hex Head Inner-Hex Body Rivet Nut

ThreadT(GRIP RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
 -0.1HBKL
M40.5-2.08.36.05.97.00.512.0
M50.5-2.58.77.06.98.00.513.0
M61.0-3.510.59.08.910.00.616.0
M81.0-3.511.311.010.912.00.6517.5
M101.0-4.012.813.012.914.50.7521.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	HB	K	L
M4	0.5-2.0	8.3	6.0	5.9	7.0	0.5	12.0
M5	0.5-2.5	8.7	7.0	6.9	8.0	0.5	13.0
M6	1.0-3.5	10.5	9.0	8.9	10.0	0.6	16.0
M8	1.0-3.5	11.3	11.0	10.9	12.0	0.65	17.5
M10	1.0-4.0	12.8	13.0	12.9	14.5	0.75	21.0

Product Specifications

Flat Head Round Body Plain Rivet Nut

ThreadT(GRIP RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M30.5-1.5
1.5-2.54.75.04.97.20.88.5
9.5
M40.5-2.0
2.0-3.56.06.05.98.50.810.5
12.0
M50.5-2.5
2.5-5.07.5
8.57.06.910.01.013.0
17.0
M60.5-3.0
3.0-5.59.29.08.912.31.315.5
18.0
M80.5-3.5
3.5-6.011.511   .010.915.01.518.5
21.0
M100.5-2.511.513.012.916.31.517
M102.5-4.0
4.0-6.012.513.012.   917.01.621.0
24.0
M101.0-3.511.012.011.916.01.619.0
M121.0-4.0
4.0-6.513.515.014.918.01.722.0
25.0
M121.0-4.016.016.015.922.02.025.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M3	0.5-1.5 1.5-2.5	4.7	5.0	4.9	7.2	0.8	8.5 9.5
M4	0.5-2.0 2.0-3.5	6.0	6.0	5.9	8.5	0.8	10.5 12.0
M5	0.5-2.5 2.5-5.0	7.5 8.5	7.0	6.9	10.0	1.0	13.0 17.0
M6	0.5-3.0 3.0-5.5	9.2	9.0	8.9	12.3	1.3	15.5 18.0
M8	0.5-3.5 3.5-6.0	11.5	11 .0	10.9	15.0	1.5	18.5 21.0
M10	0.5-2.5	11.5	13.0	12.9	16.3	1.5	17
M10	2.5-4.0 4.0-6.0	12.5	13.0	12. 9	17.0	1.6	21.0 24.0
M10	1.0-3.5	11.0	12.0	11.9	16.0	1.6	19.0
M12	1.0-4.0 4.0-6.5	13.5	15.0	14.9	18.0	1.7	22.0 25.0
M12	1.0-4.0	16.0	16.0	15.9	22.0	2.0	25.0

Product Specifications

Countersunk Head Knurled Body Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0. 1
0D
+0.07
-0.1BKL
M41.5-3.06.56.05.99.01.512.0
M51.5-3.57.57.06.910.01.513.0
M61.5-4.09.09.08.912.01.515.5
M82.0-4.511.011.010.914.01.518.5
M102.0-5.013.013.012.916.01.521.0
M122.0-5.016.516.015.919.01.524.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0. 1 0	D +0.07 -0.1	B	K	L
M4	1.5-3.0	6.5	6.0	5.9	9.0	1.5	12.0
M5	1.5-3.5	7.5	7.0	6.9	10.0	1.5	13.0
M6	1.5-4.0	9.0	9.0	8.9	12.0	1.5	15.5
M8	2.0-4.5	11.0	11.0	10.9	14.0	1.5	18.5
M10	2.0-5.0	13.0	13.0	12.9	16.0	1.5	21.0
M12	2.0-5.0	16.5	16.0	15.9	19.0	1.5	24.0

Product Specifications

Reduce Head Round Body Plain Rivet Nut

ThreadT(GRIP   RANGE)
      Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M30.5-1.56.25.04.96.00.59.0
M40.5-2.0
2.0-4.06.56.05.97.00.510.5
13.0
M50.5-2.0
2.0-4.07.07.06.98.00.511.5
13.0
M60.5-2.5
2.5-5.08.59.08.910.5
10.00.6
0.614.0
17.0
M80.5-3.0
3.0-5.010.011.010.912.00.6516.5
18.5
M100.5-3.0
3.0-5.513.013.012.914.10.717.7
21.0
M100.5-3.012.512.011.913.00.718

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M3	0.5-1.5	6.2	5.0	4.9	6.0	0.5	9.0
M4	0.5-2.0 2.0-4.0	6.5	6.0	5.9	7.0	0.5	10.5 13.0
M5	0.5-2.0 2.0-4.0	7.0	7.0	6.9	8.0	0.5	11.5 13.0
M6	0.5-2.5 2.5-5.0	8.5	9.0	8.9	10.5 10.0	0.6 0.6	14.0 17.0
M8	0.5-3.0 3.0-5.0	10.0	11.0	10.9	12.0	0.65	16.5 18.5
M10	0.5-3.0 3.0-5.5	13.0	13.0	12.9	14.1	0.7	17.7 21.0
M10	0.5-3.0	12.5	12.0	11.9	13.0	0.7	18

Product Specifications

Countersunk Head Round Body Plain Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M41.5-3.06.56.05.99.01.512.0
M51.5-3.57.57.06.910.01.513.0
M61.5-4.09.09.08.912.01.515.5
M82.0-4.511.011.010.914.01.518.5
M102.0-5.013.013.012.916.01.521.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	1.5-3.0	6.5	6.0	5.9	9.0	1.5	12.0
M5	1.5-3.5	7.5	7.0	6.9	10.0	1.5	13.0
M6	1.5-4.0	9.0	9.0	8.9	12.0	1.5	15.5
M8	2.0-4.5	11.0	11.0	10.9	14.0	1.5	18.5
M10	2.0-5.0	13.0	13.0	12.9	16.0	1.5	21.0

Product Specifications

Flat Head Knurled Body Close End Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M40.5-2.0
2.0-4.011.36.05.99.00.816.0
18.0
M50.5-3.0
2.5-5.011.57.06.910.01.017.0
19.0
M60.5-3.0
3.0-5.012.79.08.912.31.319.2
21.0
M80.5-3.0
3.0-5.514.811.010.915.01.521.5
24.0
M101.0-4.019.213.012.917.01.627.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	0.5-2.0 2.0-4.0	11.3	6.0	5.9	9.0	0.8	16.0 18.0
M5	0.5-3.0 2.5-5.0	11.5	7.0	6.9	10.0	1.0	17.0 19.0
M6	0.5-3.0 3.0-5.0	12.7	9.0	8.9	12.3	1.3	19.2 21.0
M8	0.5-3.0 3.0-5.5	14.8	11.0	10.9	15.0	1.5	21.5 24.0
M10	1.0-4.0	19.2	13.0	12.9	17.0	1.6	27.0

Product Specifications

Flat Head Full Hex Body Rivet Nut

ThreadT(GRIP   RANGE)
     Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M40.5-2.06.56.05.99.00.811.0
M50.5-2.58.07.06.910.01.014.0
M60.5-3.08.59.08.912.7(13.0)1.3515.0(16.0)
M81.0-3.510.511.010.916.01.518.0
M101.0-3.512.513.012.918.0(19.0)1.721.0(23.0)
M121.0-4.014.015.014.920.01.723.0
M101.0-3.513.512.011.918.01.721.0
M122.0-5.016.516.015.923.02.027.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	0.5-2.0	6.5	6.0	5.9	9.0	0.8	11.0
M5	0.5-2.5	8.0	7.0	6.9	10.0	1.0	14.0
M6	0.5-3.0	8.5	9.0	8.9	12.7(13.0)	1.35	15.0(16.0)
M8	1.0-3.5	10.5	11.0	10.9	16.0	1.5	18.0
M10	1.0-3.5	12.5	13.0	12.9	18.0(19.0)	1.7	21.0(23.0)
M12	1.0-4.0	14.0	15.0	14.9	20.0	1.7	23.0
M10	1.0-3.5	13.5	12.0	11.9	18.0	1.7	21.0
M12	2.0-5.0	16.5	16.0	15.9	23.0	2.0	27.0

Product Specifications

Reduce Head Knurled Body Close End Rivet Nut

ThreadT(GRIP   RANGE)
     Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M40.5-2.0
2.0-3.511.06.   05.97.00.515.0
16.5
M50.5-2.0
2.0-3.512.57.06.98.00.516.5
18.0
M60.5-3.0
3.0-4.515.59.08.9100.620.5
22.0
M80.5-3.0
3.0-4.517.011.010.912.00.6523.0
24.5
M101.0-3.0
3.0-5.018.213.012.914:00.724.5
26.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	0.5-2.0 2.0-3.5	11.0	6. 0	5.9	7.0	0.5	15.0 16.5
M5	0.5-2.0 2.0-3.5	12.5	7.0	6.9	8.0	0.5	16.5 18.0
M6	0.5-3.0 3.0-4.5	15.5	9.0	8.9	10	0.6	20.5 22.0
M8	0.5-3.0 3.0-4.5	17.0	11.0	10.9	12.0	0.65	23.0 24.5
M10	1.0-3.0 3.0-5.0	18.2	13.0	12.9	14:0	0.7	24.5 26.0

Product Specifications

Flat Head Full Hex Body Close End Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1BKL
M40.5-2.011.06.05.99.01.015.0
M50.5-2.513.57.06.910.01.018.0
M60.5-3.017.09.08.912.71.523.0
M81.0-3.519.011.010.916.01.526.0
M101.0-4.025.013.012.919.02.033.0

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	B	K	L
M4	0.5-2.0	11.0	6.0	5.9	9.0	1.0	15.0
M5	0.5-2.5	13.5	7.0	6.9	10.0	1.0	18.0
M6	0.5-3.0	17.0	9.0	8.9	12.7	1.5	23.0
M8	1.0-3.5	19.0	11.0	10.9	16.0	1.5	26.0
M10	1.0-4.0	25.0	13.0	12.9	19.0	2.0	33.0

Product Specifications

Reduce Hex Head Full-Hex Body Rivet Nut

ThreadT(GRIP RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1HBKL
M40.5-2.5
2.5-5.06.76.05.97.00.511.0
13.5
M50.5-3.0
3.0-5.09.07.06.98.00.514.5
16.0
M61.0-3.5
3.5-6.010.09.08.910.00.616.0
18.0
M81.0-4.0
4.0-6.011.511.010.912.00.6518.0
20.0
M101.0-3.5
3.5-6.012.5
14.513.012.914.50.7519.0
23.5

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	HB	K	L
M4	0.5-2.5 2.5-5.0	6.7	6.0	5.9	7.0	0.5	11.0 13.5
M5	0.5-3.0 3.0-5.0	9.0	7.0	6.9	8.0	0.5	14.5 16.0
M6	1.0-3.5 3.5-6.0	10.0	9.0	8.9	10.0	0.6	16.0 18.0
M8	1.0-4.0 4.0-6.0	11.5	11.0	10.9	12.0	0.65	18.0 20.0
M10	1.0-3.5 3.5-6.0	12.5 14.5	13.0	12.9	14.5	0.75	19.0 23.5

Product Specifications

Reduce Hex Head Full-Hex Body Colse End Rivet Nut

ThreadT(GRIP   RANGE)
Min MaxA
RerHole Size
+0.1
0D
+0.07
-0.1HB
KL
M40.5-2.512.365.970.516
M50.5-3.015.27.06.980.520
M60.5-3.514.59.08.9100.620.5
M81.0-4.017.011.010.9120.6523
M101.0-4.520.013.012.914.50.7528.5

Thread	T(GRIP RANGE) Min Max	A Rer	Hole Size +0.1 0	D +0.07 -0.1	HB	K	L
M4	0.5-2.5	12.3	6	5.9	7	0.5	16
M5	0.5-3.0	15.2	7.0	6.9	8	0.5	20
M6	0.5-3.5	14.5	9.0	8.9	10	0.6	20.5
M8	1.0-4.0	17.0	11.0	10.9	12	0.65	23
M10	1.0-4.5	20.0	13.0	12.9	14.5	0.75	28.5

Explore More Products

Self Clinching Nuts

Blind Rivet

Heavy Duty Steel Wall Anchor with Screws
